Cudy WR11000 BE11000 2.5G Mesh Wi-Fi 7 Router

Key Features

of WR11000:

6-Stream Tri-Band Wi-Fi 7

4× 2.5G Ethernet Ports

5.7 Gbps + 4.3 Gbps + 688 Mbps

Covers 140 m² (1,500 ft²) with eFEM

Cudy App, Cloud Control

Chat Through WhatsApp

Category: Cudy

Specification:

Brand	Cudy
Model	WR11000
Type	Cudy 2.5G Mesh Wi-Fi 7 Router
CPU	Chipset: Qualcomm IPQ5322 CPU Details: 1.5 GHz Quad-Core CPU
Memory/Storage	Flash/ROM: 128 MB (1 Gbit) NAND DDR/RAM: 512 MB (4 Gbit) DDR4
Wireless	6 GHz Wi-Fi Speed: 5760 Mbps 5 GHz Wi-Fi Speed: 4320 Mbps 2.4 GHz Wi-Fi Speed: 688 Mbps 6 GHz Wi-Fi Streams: 2T2R (2×2 MIMO) 5 GHz Wi-Fi Streams: 2T2R (2×2 MIMO) 2.4 GHz Wi-Fi Streams: 2T2R (2×2 MIMO) Wi-Fi Antennas: 6× Fixed 6 GHz Antenna Gain Max: 5dBi 5 GHz Antenna Gain Max: 5dBi 2.4 GHz Antenna Gain Max: 5dBi FEM or PA/LNA: 6 GHz: 2× High-Power 5 GHz: 2× High-Power 2.4 GHz: 2× Standard Beamforming: True Range Performance: Max: 260 m (853 ft) Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions. Wall Performance: Two wooden walls with thickness < 10 cm (4”) One concrete wall with thickness < 20 cm (7”) or two concrete walls with thickness < 10 cm (4”)
Interfaces	2.5G RJ45 Ports: 4 Ethernet Notes: 1× WAN port, the rest are LAN ports LED: TBD Physical Buttons: Power On/Off Button. WPS Button, Reset Button Power Input: DC Jack
Power	Power Methods: DC DC: 12V 2A Power Adapter: Input: 100 ~ 240 V, 50/60 Hz AC Output: 12V 2A DC
Reliability	Environment: Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉) Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉) Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 95% non-condensing
Installation	Desktop Wall-mount
Wireless	Wi-Fi Standards: Wi-Fi 7 Max Wi-Fi Modulation: 4K-QAM Wi-Fi Efficiency: MLO, MRU, Puncturing, OFDMA, MU-MIMO, BSS Color Max Capacity: 768 Recommended Client Upper Limit: 300 Max Wi-Fi Channel Width: 320 MHz Wi-Fi Security: WPA/WPA2/WPA3 Guest Network: 2.4 GHz, 5 GHz, 6 GHz WPS: True
General	Operation Modes: Wi-Fi Router, Access Point, Range Extender, WISP, Client Mesh: Cudy Mesh Mesh Backhaul: Wireless Backhaul, Wired Backhaul Multi-Band Backhaul: true WAN Mode: DHCP, Static IP, PPPOE Internet Failover Sequence: WAN, WISP
Network	QoS: Per-User Rate Limiting DHCP: Address Reservation, DHCP Client List, Server IP Versions: IPv4/IPv6 IPv6 Protocols: Relay, Dynamic (SLAAC/DHCPv6), Static (Fixed IP), Passthrough, 464XLAT, MAP-E, DS-Lite IPTV/VLAN: Bridge, Tag VLAN TTL Customization: Extend, Spoof, Custom IGMP: IGMP Proxy, IGMP Snooping Forwarding: Port Forwarding, Port Triggering, UPnP, DMZ Firewall: SPI Firewall, DoS Protection, Block PING Application Layer Gateway: IPSec Passthrough L2TP Passthrough PPTP Passthrough FTP Passthrough TFTP Passthrough H323 Passthrough SIP Passthrough RTSP Passthrough
Utilities	VPN Server: WireGuard, OpenVPN, IPsec, Zerotier, PPTP, L2TP VPN Client: WireGuard, OpenVPN, IPsec, Zerotier, PPTP, L2TP DNS Options: DNS over TLS, Manual DNS, Rebind Protection, Override Clients’ DNS DNS over TLS Providers: Cloudflare, Google, Quad9, Custom Wake on LAN: True Online Detection: True
Management	All Devices Management: Wi-Fi Time Schedule, MAC Filter, IP/MAC Binding Per-Devices Management: Intenent On/Off, VPN On/Off, Online Time Schedule, Device Rename Content Management: Domain Filter, IP Filter
System	LED Control: true Local Control Method: Config Web Page, App Control Remote Control Method: Config Page via HTTPS, App Control, TR069/TR098/TR111/TR181 Firmware Upgrade: Local Update, App (Over the Air), Online Update Reliability: Timed Reboot, Backup and Restore Diagnostic Tools: Diagnosis, Ping, Traceroute, NSLookup, System Log Languages: English, Bengali, Catalan, Czech, German, Greek, Spanish, French, Hebrew, Croatian, Hungarian, Italian, Japanese, Khmer, Korean, Dutch, Norwegian, Polish, Portuguese, Romanian, Russian, Slovak, Swedish, Thai, Turkish, Ukrainian, Vietnamese, Simplified Chinese, Traditional Chinese
Dashboard	Panel: Internet Status Mesh Status Devices Management WAN Status LAN Status WISP Status Wi-Fi Status VPN Status DHCP Server Status System Version Charts: Mesh Topology Internet Speed WISP Speed Wi-Fi Speed
Dimensions	Dimension: 253×152.5×48.2 mm 9.96×6×1.9 inches
Included in the Box	WR11000 Power Adapter Ethernet Cable Installation Guide
Warranty Details	1-Year Brand Warranty

Seamless Connectivity

The Cudy WR11000 BE11000 2.5G Mesh Wi-Fi 7 Router is engineered to elevate your internet experience. With advanced technology, it ensures robust connectivity throughout your home or office.

Exceptional Performance

This outstanding router supports Wi-Fi 7, delivering unparalleled speed and reliability. You can stream, game, and work with minimal interruptions, thanks to its powerful performance and efficient range.

User-Friendly Setup

Installation is simplified with the Cudy WR11000 model. Its user-friendly interface makes it easy for anyone to set up their home network quickly, providing a reliable connection for all your devices.
